In need for a quick-turn PCB prototype, a small or large batch assembly? We have got you covered. We manufacture your electronic project within two business days and ship it to you world-wide at affordable prices. Upload your project now and try out the experience that turns your electronic project into a Powerful Project without blowing your budget.Get started Technical capabilities
Printed Circuit Boards manufactured in two business days starting at just €10.16. Manufactured and delivered from Germany. 2 or 4 Layers, ENIG and HASL surface finishes and high quality base materials.Explore
Your project fully assembled. Supported by our intelligent BOM, the world's largest part catalogue and a best-in-class partner network. From prototype to series, Amazing Assembly has got you covered.Explore
This #jellybean_monday: Wire to board connectors.
Many JST series like SH and PH have become the defacto standard, with alternatives available from vendors like Würth Elektronik. Choosing these popular connectors has the benefit that preconfigured cables are easy to source.
The solder paste aperture of Heatsink/Earthpads underneath QFN/DFN/SOIC etc. packages should be adjusted to a “window pane” design for reliable soldering. This allows for flux fumes to escape more easily and prevents the building of a large solder blob that may shift the part out of position. #aisler_tips #aisler #electronics #pcb
