board preview top
board preview bottom

Readme

This project has no readme yet.

Parts

Name Description
1x TRGR1 SWITCH PUSH SPDT 0.3A 12V
1x D7 LED BLUE CLEAR 0603 SMD
1x D1 LED RGB ADDRESSABLE WS2812 5PC
1x D30 EMITTER IR 950NM 100MA RADIAL
1x D6 LED GREEN/RED CLEAR CHIP SMD
1x J10 CONN RCPT USB TYPE B 3A
1x J2 CONN D-SUB RCPT 9POS R/A SOLDER
1x BT1 CONN HEADER PH SIDE 2POS 2MM SMD
1x L50 FIXED IND 100UH 660MA 780 MOHM
1x LS1 SPEAKER 8OHM 300MW TOP PORT 92DB
1x QPWR1 MOSFET P-CH 20V 3.7A SOT-23
1x SWPRG1 SWITCH TACTILE SPST-NO 0.05A 12V
1x SWRST1 SWITCH TACTILE SPST-NO 0.05A 12V
1x U10 IC USB SERIAL BASIC UART 16SSOP
1x U50 IC LI-ION/LI-POLY CTRLR SOT23-5
1x U51 IC REG LDO 3.3V 0.5A SOT23-5
1x VBR1 VIBRATION MOTOR 3VDC
1x AMP1 IC AMP AUDIO PWR .7W MONO 8SOIC
1x U1 WIFI MODULE 64MBITS SPI FLASH
